Episode SIG-36-POINT Signature 3 6-Inch Point Speaker

Directional In-Ceiling Sound for Offset Listening Areas

The Episode SIG-36-POINT Signature 3 Series is a passive 6" in-ceiling point speaker designed for rooms where the speaker must be installed overhead but sound needs to be directed toward a seating or listening area. Its 15° angled driver orientation and adjustable tweeter provide more directional control than a conventional straight-down ceiling speaker.

Use it for media rooms, living rooms, whole-home audio, and other spaces where ceiling placement is fixed but the primary listening position is not directly underneath the speaker.

Key Specifications

• Product type: Passive directional in-ceiling speaker
• Sold as: Each
• Woofer: 6" injection-molded polypropylene cone
• Tweeter: 3/4" adjustable silk-dome tweeter
• Frequency response: 43 Hz–20 kHz
• Crossover frequency: 2.34 kHz
• Nominal impedance: 8 ohms
• Sensitivity: 89 dB
• Peak power handling: 130W
• Listening angle: 120°
• Driver angle: 15°
• Connections: Gold-plated push terminals

Who Should Choose the SIG-36-POINT?

Choose the SIG-36-POINT when a ceiling speaker needs to direct more of its output toward an offset sofa, seating area, television, or listening position.

For rooms where broad, straight-down coverage is the priority, compare it with the Episode SIG-36-IC 6" In-Ceiling Speaker.

15-Degree Directional Design

The speaker's acoustic assembly is angled approximately 15° to help direct sound toward the intended listening area rather than only downward from the ceiling.

Episode specifies a 120° listening angle, supporting broad coverage while still allowing more intentional sound placement than a conventional down-firing design.

6-Inch Polypropylene Woofer

The forward-set 6" injection-molded polypropylene woofer handles low and midrange frequencies. Episode tunes the Signature Series around low distortion, wide dispersion, and a flat frequency-response approach.

Adjustable Silk-Dome Tweeter

A 3/4" silk-dome tweeter can be adjusted to further direct high-frequency output toward the listening position.

Episode uses a vented tweeter pod designed to lower tweeter resonance and support a lower crossover point for wider dispersion.

Amplifier Compatibility

The SIG-36-POINT is an 8-ohm passive speaker with 89 dB sensitivity and requires a compatible amplifier or AV receiver.

Episode specifies 130W peak power handling. Do not treat this figure as RMS or continuous power handling.

Installation Dimensions

• Finished diameter with grille: 11"
• Ceiling cutout: 9.7" diameter
• Mounting depth: 5.2"
• Mounting depth with compatible enclosure: 6.6"
• Weight: 5.1 lb
• Supported substrate thickness: 3/8" through double 1/2"
• Recommended air volume behind speaker: 15–20 liters

Confirm joist spacing, ceiling depth, wiring, HVAC, plumbing, and other obstructions before cutting the ceiling.

Push Lock by Swarm Mounting

Episode's Push Lock by Swarm mounting system uses a tool-free locking mechanism to secure the speaker in the ceiling. The system supports both one-step and two-step installation workflows.

The SIG-36-POINT also supports compatible Episode cradles, grilles, flush-mount accessories, and an optional direct-mount backbox.

Speaker Wire

Use appropriately rated speaker wire sized for the amplifier, speaker load, and wire-run distance.

What's Included?

• 1 Episode SIG-36-POINT speaker
• Signature installation cradle
• Protective installation cover
• Compatible standard grille

Optional backbox, additional cradle, flush-mount accessories, amplifier, receiver, and speaker wire are sold separately unless otherwise specified.

Complete Your Audio System

• Episode Speakers & Audio
• Amplifiers
• Speaker Wire

Need Help Choosing the Right In-Ceiling Speaker?

Send Bear Security Shop your room dimensions, ceiling height, speaker locations, listening position, amplifier model, and intended use. We can help determine whether a directional point speaker or conventional in-ceiling design is the better fit.

What makes the SIG-36-POINT different from a standard in-ceiling speaker?

The SIG-36-POINT uses a 15° angled acoustic design and adjustable tweeter to direct more sound toward an offset listening area instead of primarily straight down.

Is the Episode SIG-36-POINT sold individually or as a pair?

It is sold individually. Order two for a conventional stereo pair or the quantity required for your home theater or distributed-audio layout.

What size woofer does it use?

The SIG-36-POINT uses a 6" injection-molded polypropylene cone woofer.

What type of tweeter does it use?

It uses a 3/4" adjustable silk-dome tweeter that can be aimed toward the listening position.

What is the impedance?

The speaker has an 8-ohm nominal impedance.

What is the sensitivity?

Episode specifies 89 dB sensitivity.

What is the frequency response?

Episode specifies a frequency response of 43 Hz–20 kHz.

What is the power handling?

Episode specifies 130W peak power handling. This is a peak specification, not an RMS rating.

What ceiling cutout is required?

The required cutout is approximately 9.7" in diameter.

How much mounting depth is required?

The speaker requires approximately 5.2" of mounting depth, or 6.6" when used with the compatible enclosure.

What is the finished diameter?

The finished diameter with the grille installed is approximately 11".

Does it require an amplifier?

Yes. The SIG-36-POINT is a passive 8-ohm speaker and requires a compatible amplifier or AV receiver.

Can it be used for home theater?

Yes. Its directional design can be useful in properly planned home theater applications where ceiling-mounted sound needs to be aimed toward the listening area.
